JUMMICO Height-Adjustable Desk 120x60cm User Manual

1. መግቢያ

This manual provides comprehensive instructions for the assembly, operation, and maintenance of your JUMMICO Height-Adjustable Desk. This electric ergonomic standing desk is designed to allow seamless transitions between sitting and standing positions, promoting a healthier work environment.

The desk features a 120 x 60 cm tabletop, integrated USB socket, cable tray, and wheels for mobility. Its robust construction supports a load capacity of up to 70 kg.

2. የደህንነት መረጃ

• Always ensure the desk is properly assembled and stable before use.
• Do not exceed the maximum weight limit of 70 kg (154 lbs) to prevent accidents or damage.
• Keep the desk away from direct heat sources and liquids to maintain its longevity and ensure safe operation.
• Ensure there are no obstructions in the desk's path during height adjustment to prevent damage or injury. The desk is equipped with an anti-collision feature.
• በቀዶ ጥገና ወቅት ልጆችን እና የቤት እንስሳትን ከጠረጴዛው ያርቁ።

3. የጥቅል ይዘቶች

Please verify that all components are present before beginning assembly. A detailed installation guide is included in the product packaging.

• Tabletop (multi-section)
• Desk Frame (legs and crossbars)
• የመቆጣጠሪያ ፓነል ከ LED ማሳያ ጋር
• የኃይል አስማሚ እና ገመድ
• የኬብል ትሪ
• ዊልስ (4 ክፍሎች)
• Headphone Hooks (2 units)
• የመገጣጠሚያ ሃርድዌር (ዊንጮች፣ መሳሪያዎች)

4. ማዋቀር እና መሰብሰብ

The JUMMICO desk is designed for straightforward assembly, typically completed within 30 minutes. All necessary tools and detailed instructions are provided in the package. The tabletop sections feature pre-drilled holes for easy alignment.

ምስል 4.1፡ Exploded diagram showing the main components of the JUMMICO desk, highlighting that assembly is designed to be completed in approximately 30 minutes with pre-drilled holes and included tools.

የመሰብሰቢያ ደረጃዎች

1. ሁሉንም ክፍሎች ያላቅቁ እና ከጥቅሉ ይዘቶች ዝርዝር ጋር ያረጋግጡ።
2. Assemble the desk frame according to the detailed instructions provided.
3. Attach the tabletop sections to the assembled frame, ensuring all screws are securely fastened.
4. Install the control panel in the designated slot on the tabletop.
5. Attach the cable tray, wheels, and headphone hooks as desired.
6. Connect the power adapter to the control panel and a suitable power outlet.

5. የአሠራር መመሪያዎች

The JUMMICO desk offers intuitive controls for height adjustment and additional features.

ምስል 5.1፡ This image illustrates the JUMMICO height-adjustable desk in both sitting (minimum 73cm) and standing (maximum 118cm) positions, demonstrating its adaptability for various user heights and work preferences.

የቁጥጥር ፓነል ተግባራት፡-

ምስል 5.2፡ This image focuses on the intelligent control panel, featuring an LED screen, buttons for height adjustment, two memory preset buttons, a USB charging port, and an activity reminder function.

• የ LED ማያ ገጽ Displays the current desk height in centimeters.
• የላይ/ታች አዝራሮች Press and hold to adjust the desk height continuously between 72 cm and 116 cm.
• Memory Presets (1, 2): Press 'M' then a number (1 or 2) to save the current height. To recall a saved height, simply press the corresponding number button.
• የዩኤስቢ ኃይል መሙያ ወደብ Located on the control panel, allows direct charging of various devices.
• የእንቅስቃሴ አስታዋሽ፡- Set reminder alarms for 0.5, 1, or 2 hours to prompt you to switch between sitting and standing positions.

Anti-Collision Protection:

The desk is equipped with an intelligent anti-collision system. If the desk encounters an obstruction during height adjustment, it will automatically stop and slightly reverse its movement to prevent damage or injury.

ምስል 5.3፡ A visual representation demonstrating the ultra-quiet operation of the JUMMICO desk's motor, producing less than 55dB, significantly quieter than typical motors and normal conversation levels. The image also references intelligent rebound in case of obstruction.

6. Features and Design Elements

ጠንካራ ግንባታ;

The JUMMICO electric desk is supported by a sturdy T-shaped metal frame, constructed from industrial steel, combined with a durable laminate tabletop. This design ensures a load capacity of 70 kg. The stability of the frame and the durability of the motor have been tested over 20,000 cycles.

ምስል 6.1፡ This image details key design elements such as the robust reinforced steel frame, integrated cable management grommets for an organized workspace, and convenient hooks for headphones or bags.

ምስል 6.2፡ A visual test showing the JUMMICO desk's exceptional stability, even at its maximum height, by demonstrating that dominoes placed on the surface remain standing during height adjustments, unlike other desks.

አሳቢ ንድፍ;

• የኬብል ትሪ፡ An integrated cable tray helps manage and conceal cables, maintaining a tidy workspace.
• መንኮራኩሮች፡ Four included wheels allow for easy repositioning of the desk.
• Headphone Hooks: Two hooks are provided for convenient storage of headphones or bags.

7. ጥገና እና እንክብካቤ

• ሁሉንም ዊንጮችና ግንኙነቶች በጥብቅ እንዲቆዩ በየጊዜው ይመርምሩ።
• Clean the desk surface with a soft, damp ጨርቅ። ሻካራ ማጽጃዎችን ወይም ጠጣር ኬሚካሎችን ያስወግዱ።
• ሞተሩን እና የኤሌክትሪክ ክፍሎችን ከአቧራ እና ከእርጥበት ነጻ ያድርጉት።
• Do not place hot items directly on the tabletop without protection.
• የኃይል ገመዱ አለመቆነጡን ወይም አለመጎዳቱን ያረጋግጡ።

8. መላ መፈለግ

If you encounter any issues with your JUMMICO desk, please refer to the following common solutions:

• ዴስክ የማይንቀሳቀስ; Check if the power cable is securely connected to both the desk and the power outlet. Ensure the outlet is functional.
• ያልተስተካከለ እንቅስቃሴ; Ensure the desk is placed on a level surface. Check for any obstructions beneath the desk.
• በማሳያው ላይ የስህተት ኮድ፡- Refer to the detailed installation guide for specific error code meanings and troubleshooting steps. Often, unplugging the desk for 30 seconds and plugging it back in can reset the system.
• Anti-Collision Triggered Frequently: Ensure there are no items or walls too close to the desk's moving parts.

ችግሮች ከቀጠሉ፣ እባክዎ የደንበኞች ድጋፍን ያነጋግሩ።

9. ዝርዝሮች

ምስል 9.1፡ This diagram provides precise measurements of the JUMMICO desk, including the 120cm x 60cm tabletop, height range from 73cm to 118cm, and base dimensions, crucial for planning your workspace.

10. የዋስትና መረጃ

JUMMICO offers a የ 3 ዓመት ዋስትና on the motor and a የ 5 ዓመት ዋስትና on the table frame, effective from the date of purchase. This warranty covers manufacturing defects and ensures the quality and durability of your product.

11. የደንበኛ ድጋፍ

For any installation problems, repair inquiries, or spare parts requests, please contact JUMMICO customer service. Our support team is committed to responding within 24 hours, including weekends.

Please refer to your purchase documentation for specific contact details or visit the official JUMMICO webጣቢያ.
