መግቢያ
Thank you for choosing the PEIZIBM D6 Air Drone. This manual provides essential information for the safe and efficient operation of your new drone. Please read it thoroughly before first use and retain it for future reference.
The D6 Air Drone features obstacle avoidance technology and a foldable design, making it suitable for both beginners and experienced pilots. Proper setup and understanding of controls are crucial for an enjoyable flight experience.
የደህንነት መመሪያዎች
- ድሮን ሁል ጊዜ ከሰዎች፣ ከእንስሳት እና እንቅፋት ርቀው በሚገኙ ክፍት ቦታዎች ላይ ያንቀሳቅሱት።
- አየር ማረፊያዎች፣ የተገደበ የአየር ክልል ወይም ሚስጥራዊነት ያላቸው ጭነቶች አጠገብ አይበሩ።
- ከእያንዳንዱ በረራ በፊት ባትሪው ሙሉ በሙሉ መሙላቱን ያረጋግጡ።
- በጠንካራ ንፋስ ወይም መጥፎ የአየር ሁኔታ ከመብረር ተቆጠብ።
- ጣቶችን እና አልባሳትን ከሚሽከረከሩ ማራመጃዎች ያርቁ።
- በድሮን ኦፕሬሽን ወቅት ልጆችን ይቆጣጠሩ።
- Adhere to all local laws and regulations regarding drone usage.
1. ማዋቀር
1.1 ድሮኑን በማጠፍ ላይ
Gently unfold the drone arms until they lock into position. Ensure all four arms are fully extended.
Image: The PEIZIBM D6 Air Drone with its arms unfolded, ready for propeller installation.
1.2 ባትሪ መጫን እና መሙላት
- Insert the drone battery into the battery compartment until it clicks securely.
- Connect the charging cable to the battery and a suitable USB power adapter (not included).
- በቻርጀር ላይ ያለው የአመላካች መብራት የኃይል መሙያ ሁኔታን ያሳያል (ለምሳሌ፣ ለኃይል መሙያ ቀይ፣ ሙሉ በሙሉ ለመሙላት አረንጓዴ)።
- Charging typically takes 60-90 minutes. Do not overcharge.
1.3 የፕሮፔለር መጫኛ
The drone comes with propellers pre-installed. If replacement is needed:
- Identify propellers marked 'A' and 'B'.
- Match 'A' propellers to motor shafts marked 'A' and 'B' propellers to motor shafts marked 'B'.
- Press down firmly until the propeller is seated correctly.
1.4 የርቀት መቆጣጠሪያ ማዋቀር
- Install 3x AAA batteries (not included) into the remote controller.
- በድሮን ላይ ኃይል, ከዚያም በርቀት መቆጣጠሪያው ላይ ኃይል.
- Push the left joystick up then down to pair the drone with the controller. A beep will confirm successful pairing.
2. የአሠራር መመሪያዎች
2.1 መሰረታዊ የበረራ መቆጣጠሪያዎች
| Control Stick/Button | ተግባር |
|---|---|
| የግራ ጆይስቲክ (ወደላይ/ወደታች) | ስሮትል (ወደላይ/ወደታች) |
| Left Joystick (Left/Right) | Yaw (Rotate Left/Right) |
| Right Joystick (Up/Down) | Pitch (Forward/Backward) |
| Right Joystick (Left/Right) | Roll (Left/Right Sideways Flight) |
| የአንድ-ቁልፍ መውረጃ/ማረፊያ አዝራር | አውቶማቲክ መነሳት ወይም ማረፍን ይጀምራል። |
| የአደጋ ጊዜ ማቆሚያ ቁልፍ | Immediately stops all motors. Use only in emergencies. |
2.2 እንቅፋት ማስወገድ
The D6 Air Drone is equipped with sensors for obstacle avoidance. This feature helps prevent collisions by automatically adjusting flight path when obstacles are detected. This system is most effective at lower speeds and in well-lit environments. It may not detect all obstacles, especially thin wires or transparent surfaces.
2.3 የካሜራ አሠራር
If your D6 Air Drone model includes a camera:
- Connect your smartphone to the drone's Wi-Fi network (refer to the app manual for details).
- Open the dedicated drone app to view the live feed and control camera functions.
- Use the app to take photos or record videos. Files are typically saved to your smartphone or an inserted SD card (if applicable).
3. ጥገና
3.1 ጽዳት
Regularly clean the drone body and propellers with a soft, dry cloth. Avoid using liquids or solvents that could damage electronic components.
3.2 የፕሮፔለር መተካት
Inspect propellers for damage before each flight. Replace any bent, cracked, or chipped propellers immediately. Use the provided propeller removal tool (if included) and follow the installation steps in Section 1.3.
3.3 የባትሪ እንክብካቤ
- ባትሪዎችን በቀጥታ ከፀሀይ ብርሀን እና ከከፍተኛ ሙቀት ርቀው በቀዝቃዛና ደረቅ ቦታ ያከማቹ።
- ሙሉ በሙሉ የተሞሉ ወይም ሙሉ በሙሉ የተሟሉ ባትሪዎችን ለረጅም ጊዜ አያስቀምጡ። ለረጅም ጊዜ ማከማቻ ከ50-60% ባለው ኃይል ይሙሉ።
- If a battery appears swollen or damaged, discontinue use and dispose of it properly.
4. መላ መፈለግ
| ችግር | ሊሆን የሚችል ምክንያት | መፍትሄ |
|---|---|---|
| ድሮን አይበራም። | ባትሪ አልተሞላም ወይም በስህተት አልተጫነም። | ባትሪው ሙሉ በሙሉ መሙላቱን እና ደህንነቱ በተጠበቀ ሁኔታ መጨመሩን ያረጋግጡ። |
| ድሮን ለመቆጣጠሪያው ምላሽ አይሰጥም። | Not paired, low controller battery, or interference. | Re-pair the drone and controller. Replace controller batteries. Move to an area with less interference. |
| በበረራ ወቅት ድሮን ይንቀሳቀሳል። | Uncalibrated gyroscope, uneven propellers, or wind. | Perform gyroscope calibration (refer to controller instructions). Check and replace damaged propellers. Fly in calm conditions. |
| Camera not working/no live feed. | App not connected, Wi-Fi issue, or camera malfunction. | ስልኩ ከድሮን ዋይፋይ ጋር መገናኘቱን ያረጋግጡ። መተግበሪያውን እና ድሮኑን እንደገና ያስጀምሩ። |
5. ዝርዝሮች
| ባህሪ | ዝርዝር |
|---|---|
| የምርት ስም | PEIZIBM |
| ሞዴል | D6 Air Drone |
| ቀለም | ጥቁር |
| እንቅፋት ማስወገድ | አዎ |
| ሊታጠፍ የሚችል ንድፍ | አዎ |
| የኃይል ምንጭ | Rechargeable Battery (Drone), AAA Batteries (Controller) |
6. ዋስትና እና ድጋፍ
This product comes with a standard manufacturer's warranty. Please refer to the packaging or the official PEIZIBM webጣቢያ ለተወሰኑ የዋስትና ውሎች እና ሁኔታዎች።
For technical support, troubleshooting assistance, or spare parts, please contact PEIZIBM customer service through their official channels. Keep your purchase receipt as proof of purchase.
