Weiser Augusta/Troy Single Cylinder Handleset

1. መግቢያ

This manual provides comprehensive instructions for the installation, operation, and maintenance of your Weiser Augusta/Troy Single Cylinder Handleset. This handleset is designed for residential and light commercial applications, offering security and durability with an ANSI Grade 2 rating. Please read all instructions carefully before beginning installation to ensure proper function and safety.

2. የደህንነት መረጃ

• በሚጫኑበት ጊዜ ሁልጊዜ እንደ የደህንነት መነጽር ያሉ ተገቢ የደህንነት መሳሪያዎችን ይልበሱ።
• የመታፈን አደጋዎችን ለመከላከል ትናንሽ ክፍሎችን ከልጆች ያርቁ።
• Use only the tools specified or recommended in this manual.
• Ensure all screws are tightened securely, but do not overtighten, as this may damage components.
• If you are unsure about any part of the installation process, consult a qualified locksmith or professional installer.

3. የጥቅል ይዘቶች

መጫኑን ከመጀመርዎ በፊት ሁሉም አካላት መኖራቸውን ያረጋግጡ-

• Exterior Handleset Assembly (Augusta/Troy Trim)
• Interior Knob Trim
• Deadbolt Latch
• ጸደይ ላች
• Strike Plates (Full Lip)
• ማፈናጠጥ ብሎኖች
• ቁልፎች
• የመጫኛ አብነት (ከተካተተ)

4. መጫን

የሚያስፈልጉ መሳሪያዎች፡- Phillips head screwdriver, tape measure, pencil, drill (optional for new installations).

ምስል 1 - ተጠናቀቀview of the Weiser Augusta/Troy Single Cylinder Handleset components, including the exterior handle, interior knob, and associated hardware.

1. በሩን ያዘጋጁ; Ensure your door has the correct bore holes and backset. This handleset is designed for doors with a 2-1/8 inch cross bore and an adjustable backset of 2-3/8 inches or 2-3/4 inches.
2. የዴድቦልት መቆለፊያውን ይጫኑ፦ Insert the deadbolt latch into the edge bore hole, ensuring the bolt faces the correct direction. Secure it with the provided screws.
3. Install the Spring Latch: Insert the spring latch into the lower edge bore hole, ensuring the bevel faces the door frame. Secure it with the provided screws.
4. የውጪውን መያዣ ይጫኑ፦ Place the exterior handleset assembly onto the door, aligning the posts with the bore holes.
5. Install the Interior Knob Trim: Attach the interior knob trim to the exterior handleset, ensuring the spindle engages with the spring latch mechanism. Secure with the long mounting screws, tightening evenly.
6. የሙከራ ተግባር Before closing the door, test the deadbolt and spring latch mechanisms to ensure smooth operation. The deadbolt should extend and retract fully with the key from either side. The lower trim is non-locking.
7. አድማ ሳህኖችን ጫን፡- Mark and chisel out recesses for the strike plates on the door frame, aligning them with the latches. Secure the strike plates with the provided screws.

5. ኦፕሬሽን

• የዴድቦልቱን መቆለፍ፡ Insert the key into the exterior cylinder and turn to extend the deadbolt. From the interior, turn the thumbturn to extend the deadbolt.
• የዴድቦልቱን መክፈት፦ Insert the key into the exterior cylinder and turn to retract the deadbolt. From the interior, turn the thumbturn to retract the deadbolt.
• Operating the Lower Latch: The lower handle operates a spring latch for entry and exit. This latch does not lock and is always accessible from both sides.

6. ጥገና

• ማጽዳት፡ Clean the handleset with a soft, damp ጨርቅ። ሻካራ ማጽጃዎችን፣ መሟሟቶችን ወይም ጠጣር ኬሚካሎችን ያስወግዱ፣ ምክንያቱም እነዚህ ጨርቁን ሊጎዱ ይችላሉ።
• ቅባት፡ በየጊዜው አነስተኛ መጠን ያለው የግራፋይት ቅባት ወይም በሲሊኮን ላይ የተመሠረተ ስፕሬይ ወደ ቁልፍ መንገድ እና ውስጣዊ ሜካኒዝም ይቀቡ። በዘይት ላይ የተመሰረቱ ቅባቶችን አይጠቀሙ።
• ምርመራ፡- Regularly check all screws for tightness and ensure the handleset operates smoothly. Tighten any loose screws as needed.

7. መላ መፈለግ

• Handleset is stiff or difficult to operate:
  • Check if mounting screws are overtightened. Loosen slightly if necessary.
  • Apply lubricant to the latch and cylinder mechanisms.
  • Ensure the door is properly aligned and not binding against the frame.
• ዴድቦልት ሙሉ በሙሉ አይዘረጋም ወይም ወደኋላ አይመለስም፦
  • Verify the strike plate alignment. Adjust if the deadbolt is hitting the frame or strike plate.
  • Check for obstructions in the door frame.
• ቁልፉ ለማስገባት ወይም ለመገልበጥ አስቸጋሪ ነው፡
  • Apply graphite lubricant to the keyway.
  • Ensure the key is not bent or damaged.

8. ዝርዝሮች

9. ዋስትና እና ድጋፍ

Weiser products are manufactured to the highest standards and are backed by a limited lifetime warranty on mechanical components and finish. For detailed warranty information, technical support, or to purchase replacement parts, please visit the official Weiser webጣቢያ ወይም የደንበኞች አገልግሎት ክፍልን ያነጋግሩ። ለዋስትና ጥያቄዎች የግዢ ማረጋገጫዎን ያስቀምጡ።
