መግቢያ
This manual provides essential information for the safe and efficient operation, maintenance, and troubleshooting of your RYOBI 40V Battery Topper Fan, Model RY40CF01B. Please read this manual thoroughly before using the product.
The RYOBI 40V Battery Topper Fan is designed to provide portable airflow with three speed settings and a multi-directional pivoting head. It features a 2-by metal hanging hook for versatile mounting and an integrated USB-C port for charging mobile devices.
ጠቃሚ የደህንነት መረጃ
ይህንን ምርት ሲጠቀሙ ሁልጊዜ የእሳት፣ የኤሌክትሪክ ንዝረት እና የግል ጉዳት ስጋትን ለመቀነስ መሰረታዊ የደህንነት ጥንቃቄዎችን ይከተሉ።
- ከመጠቀምዎ በፊት ሁሉንም መመሪያዎች ያንብቡ.
- Do not expose the fan to rain or wet conditions.
- ማራገቢያውን በተበላሸ ገመድ ወይም መሰኪያ አያሰራው.
- Keep fingers and other objects away from the fan blades.
- Use only RYOBI 40V batteries with this fan.
- Do not attempt to service the fan beyond what is described in this manual.
- ከማጽዳትዎ ወይም ማንኛውንም ጥገና ከማድረግዎ በፊት የባትሪውን ጥቅል ሁልጊዜ ያስወግዱ።
የጥቅል ይዘቶች
- (1) RYOBI 40V Battery Topper Fan (Model RY40CF01B)
- መመሪያ መመሪያ
ማስታወሻ፡ ባትሪ እና ቻርጅር የሚሸጡት ለየብቻ ነው።
ማዋቀር
1. የባትሪ ጭነት
Ensure the fan is turned off before installing or removing the battery.
- የጎድን አጥንቶቹን በባትሪ ፓኬጁ ላይ ካለው የአየር ማራገቢያ ባትሪ ወደብ ጋር ያስተካክሉ።
- Insert the battery pack into the fan until it clicks securely into place.
- ለማስወገድ የባትሪ መልቀቂያ አዝራሩን ይጫኑ እና የባትሪውን ጥቅል ይጎትቱ።

Image: The RYOBI 40V Battery Topper Fan with a 40V battery pack securely installed in the top compartment. The fan head is visible, along with the control panel.
2. የመጫኛ አማራጮች
The fan features a 2-by metal hanging hook for versatile placement.
- ማንጠልጠል፡ Extend the metal hook and hang the fan on a suitable support structure (e.g., a 2x4 stud, pipe, or hook). Ensure the support is stable and can bear the fan's weight.
- ራሱን ችሎ የቆመ: ማራገቢያውን በጠፍጣፋ እና በተረጋጋ መሬት ላይ ያስቀምጡት.
Adjust the multi-directional pivoting head to direct airflow as needed.
የአሠራር መመሪያዎች
1. ማብራት / ማጥፋት
Press the power button located on the control panel to turn the fan on or off.
2. የደጋፊ ፍጥነት ማስተካከል
The fan has three speed settings: Low, Medium, and High. Press the speed control button repeatedly to cycle through the desired speed.
- ዝቅተኛ ፍጥነት; Provides extended runtime for gentle air circulation.
- መካከለኛ ፍጥነት፡ Balances airflow and runtime.
- ከፍተኛ ፍጥነት፡ Delivers maximum airflow for rapid cooling or ventilation.
3. የዩኤስቢ-ሲ ባትሪ መሙያ ወደብ
The integrated USB-C port allows you to charge mobile devices. Connect your device's USB-C cable to the fan's USB-C port. The fan does not need to be operating to use the charging port, as long as a charged battery is installed.
ጥንቃቄ፡-
Do not use the USB-C port to charge the fan's 40V battery. This port is for charging external devices only.
ጥገና
መደበኛ ጥገና ጥሩ አፈፃፀምን ያረጋግጣል እና የአድናቂዎን ዕድሜ ያራዝማል።
1. ማጽዳት
ከማጽዳትዎ በፊት ሁልጊዜ የባትሪውን መያዣ ያስወግዱ.
- ለስላሳ ይጠቀሙ, መamp የማራገቢያውን ውጫዊ ገጽታዎች ለማጽዳት ጨርቅ።
- Do not use harsh chemicals, abrasive cleaners, or solvents, as these may damage plastic parts.
- Periodically clean the fan blades and grille to remove dust and debris. A vacuum cleaner with a brush attachment can be used.
2. ማከማቻ
When not in use, store the fan in a clean, dry place, out of reach of children. Remove the battery pack for long-term storage.
መላ መፈለግ
| ችግር | ሊሆን የሚችል ምክንያት | መፍትሄ |
|---|---|---|
| ደጋፊ አይበራም። | ባትሪ በትክክል አልተጫነም። | የባትሪው ጥቅል ሙሉ በሙሉ እንደገባ እና ወደ ቦታው ጠቅ ማድረጉን ያረጋግጡ። |
| ባትሪ ተለቅቋል። | Charge the battery pack using a compatible RYOBI 40V charger. | |
| ደጋፊ ተጎድቷል። | ለእርዳታ የደንበኛ ድጋፍን ያነጋግሩ። | |
| የተቀነሰ የአየር ፍሰት. | Fan blades or grille are obstructed. | Remove battery, then clean fan blades and grille. |
| USB-C port not charging devices. | Battery is discharged or not installed. | Ensure a charged battery is installed. |
| የመሳሪያው ገመድ ጉድለት አለበት። | የተለየ የዩኤስቢ-ሲ ገመድ ወይም መሳሪያ ይሞክሩ። |
ዝርዝሮች
- ሞዴል፡ RY40CF01B
- የምርት ስም፡ ራይቢ
- ጥራዝtage: 40 ቪ ዲ.ሲ
- የአየር ፍሰት አቅም; 260 ሲኤፍኤም
- የደጋፊ ፍጥነት ቅንብሮች፡- 3 (ዝቅተኛ፣ መካከለኛ፣ ከፍተኛ)
- ልዩ ባህሪያት፡ Multi-directional pivoting head, 2-by metal hanging hook, USB-C charging port
- ልኬቶች (ምርት): 6 x 6 x 9 ኢንች
- የኃይል ምንጭ፡- Battery Powered (RYOBI 40V)
- የቤት ውስጥ/የውጭ አጠቃቀም፡- የቤት ውስጥ ፣ ከቤት ውጭ
የዋስትና መረጃ
This RYOBI 40V Battery Topper Fan (Model RY40CF01B) is backed by a 3-year manufacturer's warranty. This warranty covers defects in material and workmanship from the date of purchase. Please retain your proof of purchase for warranty claims. For full warranty details and conditions, please refer to the official RYOBI webጣቢያ ወይም የደንበኛ ድጋፍን ያነጋግሩ።
የደንበኛ ድጋፍ
For technical assistance, replacement parts, or warranty inquiries, please contact RYOBI customer support.
Webጣቢያ፡ www.ryobitools.com
ስልክ፡ RYOBI ን ይመልከቱ webለክልላዊ አድራሻ ቁጥሮች ጣቢያ.
When contacting support, please have your product model number (RY40CF01B) and serial number (if applicable) ready.
