iVANKY 80Gbps 16K DisplayPort 2.1 Cable (2M) Instruction Manual

1. መግቢያ

This manual provides comprehensive instructions for the iVANKY 80Gbps 16K DisplayPort 2.1 Cable. This cable is engineered to facilitate high-bandwidth video and audio transmission between DisplayPort-enabled devices, supporting advanced resolutions and refresh rates for an optimal visual and auditory experience.

Image: iVANKY 80Gbps 16K DisplayPort 2.1 Cable, showcasing its ability to deliver ultra-high precision visuals for future display possibilities.

2. ቁልፍ ባህሪያት

• VESA Certified 80Gbps Bandwidth: This iVANKY 16K DisplayPort 2.1 cable is VESA certified, ensuring maximum performance for next-generation displays. It supports an ultra-high bandwidth of 80Gbps, enabling resolutions up to 16K@60Hz, 8K@120Hz, 4K@240Hz, and 2K@360Hz. It is backward compatible with DisplayPort 2.0, 1.4, and 1.2, and supports uncompressed 7.1/5.1/2.0 channel audio passthrough.

Image: DisplayPort 2.1 bandwidth performance is three times higher than previous versions, reaching 80Gbps.
• Advanced Gaming Performance: This 16K DisplayPort cable supports VRR (Variable Refresh Rate), ALLM (Auto Low Latency Mode), and Adaptive-Sync, minimizing latency and eliminating screen tearing for smooth gameplay. It is compatible with G-Sync and FreeSync technologies and supports Dynamic HDR for vivid contrast and vibrant graphics.


Image: The cable supports 16K@60Hz, 8K@120Hz, and 4K@240Hz, enabling clearer gameplay.

• ዘላቂ ግንባታ; The cable features tinned copper conductors and multi-layer shielding to effectively block electromagnetic interference, ensuring stable signal transmission over long periods. Its nylon braided exterior offers 10 times greater durability than PVC, and 24K gold-plated connectors prevent corrosion, guaranteeing a secure connection.

Image: High-quality construction details including aluminum alloy casing, durable nylon braiding, and gold-plated connectors.
• ሰፊ ተኳኋኝነት This monitor cable connects seamlessly with DisplayPort-enabled monitors, GPUs (e.g., RTX 5090, AMD RX 7900XTX high-end models), and laptops (including gaming displays from Alienware, BenQ, Odyssey series). It supports MST (Multi-Stream Transport), enabling multi-monitor workflows and enhanced productivity.

3. የማዋቀር መመሪያዎች

1. ወደቦችን መለየት፡- Locate the DisplayPort output on your source device (e.g., computer, graphics card) and the DisplayPort input on your display device (e.g., monitor, TV).
2. ገመድ ማገናኘት; Insert one end of the iVANKY DisplayPort 2.1 cable into the DisplayPort output of your source device.
3. ደህንነቱ የተጠበቀ ግንኙነት; Insert the other end of the cable into the DisplayPort input of your display device. Ensure both connectors are fully seated and secure. The DisplayPort connectors typically have a latching mechanism; press the release button on the connector before unplugging.
4. አብራ፡ የምንጭ መሳሪያዎን እና የማሳያ መሳሪያዎን ሁለቱንም ያብሩ።
5. ግቤትን ይምረጡ፡- Your display should automatically detect the signal. If not, use your display's on-screen menu to manually select the correct DisplayPort input.

4. የአሠራር መመሪያዎች

1. መሰረታዊ ተግባር፡- Once connected, the cable will transmit video and audio signals between your devices. No additional software or drivers are typically required for basic functionality.
2. የማሳያ ቅንብሮችን ያስተካክሉ፡ To utilize the cable's full capabilities (e.g., 16K@60Hz, 8K@120Hz, 4K@240Hz, HDR, G-Sync/FreeSync), adjust the resolution, refresh rate, and other display settings through your operating system's display settings or your graphics card's control panel.
3. Multi-Monitor Setup (MST): For connecting multiple monitors to a single DisplayPort output (if supported by your graphics card and monitors), configure the display modes (Extended, Mirrored, or Multi-Stream Transport) via your operating system's display settings.


Image: The cable supports various display configurations including Extended Mode, Mirror Mode, and Multi-screen Composite Mode for enhanced productivity and immersive experiences.

5. ጥገና

• ማከማቻ፡ ገመዱን በማይጠቀሙበት ጊዜ ከቀጥታ የፀሐይ ብርሃን እና ከፍተኛ የሙቀት መጠን ራቅ ባለ ቀዝቃዛና ደረቅ ቦታ ያስቀምጡ።
• አያያዝ፡ Avoid sharp bends, kinks, or excessive pulling on the cable to prevent internal wire damage. Always grasp the connector housing when plugging or unplugging the cable.
• ማጽዳት፡ Periodically clean the connectors with a dry, lint-free cloth to remove dust or debris that could interfere with signal transmission. Do not use liquid cleaners directly on the connectors.

6. መላ መፈለግ

• ምንም ምልክት / ጥቁር ማያ;
  • የDisplayPort ኬብል ሁለቱም ጫፎች ከምንጩ እና ከማሳያ መሳሪያዎች ጋር ደህንነቱ በተጠበቀ ሁኔታ መገናኘታቸውን ያረጋግጡ።
  • Verify that the correct input source (DisplayPort) is selected on your monitor or TV.
  • Test the cable with another DisplayPort-enabled device or try a different DisplayPort cable to isolate the issue.
  • የግራፊክስ ካርድ ነጂዎችን ወደ የቅርብ ጊዜው ስሪት ያዘምኑ።
• ማብረር/ማቆራረጥ የሚችል ምልክት፦
  • Check the cable and connectors for any visible physical damage.
  • Reduce the display resolution or refresh rate in your operating system settings to see if the issue resolves.
  • Ensure your graphics card and monitor fully support the selected resolution and refresh rate.
  • Route the DisplayPort cable away from power cables or other electronic devices that might cause electromagnetic interference.
• ኦዲዮ የለም፡
  • Confirm that DisplayPort audio is enabled in your operating system's sound settings.
  • Ensure your display device has built-in speakers or is connected to external audio output devices.
  • Check the audio output settings on your source device to ensure DisplayPort is selected as the output.

7. ዝርዝሮች

Image: Detailed specifications for the iVANKY DisplayPort 2.1 cable, highlighting its capabilities and compatibility.

8. ዋስትና እና ድጋፍ

iVANKY is committed to providing high-quality hardware and excellent customer support. Each iVANKY DisplayPort cable undergoes rigorous testing to meet the highest quality standards.

• የደንበኛ ድጋፍ፡ A friendly support team is available to assist you within 24 hours.
• የቴክኒክ ድጋፍ; Professional technical support is provided to all customers.
• ዋስትና፡- Under certain conditions, customers can benefit from a customer support period of up to 54 months. Please refer to iVANKY's official website or product packaging for specific warranty terms and conditions.
